Description
Horizontal Hot Chamber Pressure Die Casting Machines suitable for the production of large parts with high strength requirements. At present, we produce hot chamber die casting machines from 40 Tonnes to 130 Tonnes, including TDC 40T, TDC 50T, TDC 90T and TDC 130T.
| Clamping Force | 50 | Ton |
| Space between Tie Bars | 290*290 | mm |
| Die Opening Stroke | 230 | mm |
| Die Height (Min – Max) | 100 – 330 | mm |
| Platen Size | 460*460 | mm |
| Ejection Force | 3 | Ton |
| Ejection Stroke | 60 | mm |
| Injection Force | 4 | Ton |
| Injection Stroke | 125 | mm |
| Nozzle Traverse Stroke | 180 | mm |
| Shot Position | 0 – 40 | mm |
| Plunger Diameter | 40 – 50 | mm |
| Shot Weight | 0.8.1.0 | |
| Melting Pot Capacity | 250 | Kg(Zn) |
| System Working Pressure | 90 | bar |
| Motor Capacity | 7.5 | Kw |
| Oil Tank Capacity | 210 | L |
| Nozzle Heater Consumption | 1.5 | Kw |
| Diesel Furnace Consumption | 4 | Kg/h |
| Machine Weight | 3.5 | Ton |
Features:
- Three Stage Injection
- Centre and Bottom Injection Position
- Centralized Lubrication
- Simple Hydraulic System
- Heat Exchanger incorporated in return flow
- Hand and Semi-Automatic Cycle Operation
- Built-in provision for core cylinder
- Provision for zero leakage of nitrogen gas
